Product Hierarchy
Product Hierarchy

FCSD12LDFS - FX DCX Splice Cassette, OS2, 12 Ports LC Duplex


FX DCX Splice Cassette, OS2, 12 Ports LC Duplex, Blue Adapters

Product Overview

Suitable Applications: DCX, Data Centers, Central Equipment Room

Construction

Weight: 0.360 lbs
Height: 0.500 in
Width: 6.830 in
Depth: 7.190 in

Physical Specifications

Max Capacity: 24 Fibers

Temperature Range

Operating Temp Range: -10°C to +60°C
Storage Temp Range: -10°C to +75°C

Product Material

Materials
DescriptionMaterialColorType
Cassette AssemblyPlastic - UL94V-0Black
Front Connector BodyPlastic - UL94V-0BlueLC Duplex
Adapter SleeveZirconia-Ceramic

Standards

EU RoHS Compliance Date (yyyy-mm-dd): 2013-01-11
MII Order #39 (China RoHS): EUP 50

Part Number

Included Parts: Cable rubber retention (2mm, 3mm)
Related Parts: DCX Frames, Modules, and Patch Panels
Variants
Item #Connector Type
FCSD12LDFSLC Duplex

Product Notes

Packaging: Individually packaged in a plastic shell, Shipped in cardboard box

History

Update and Revision: Revision Number: 0.29 Revision Date: 01-21-2021
Date: 2013-01-11
No accessories are available for this product
