(10)| Suitable Applications: | for use with automatic stripping equipments; low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; computer communication; panel wiring |
| Element | AWG | Stranding | Material | No. of Pairs |
|---|---|---|---|---|
| Pair(s) | 22 | 7x30 | TC - Tinned Copper | 2 |
| Conductor Count: | 4 |
| Element | Material | Nominal Diameter | Nominal Wall Thickness |
|---|---|---|---|
| Pair(s) | FEP - Fluorinated Ethylene Propylene | 0.044 in | 0.007 in |
| Number | Color |
|---|---|
| 1 | Black & Red |
| 2 | Black & White |
| Type | Material | Material Trade Name | Coverage [%] | Drainwire Material | Drainwire AWG | Drainwire Construction n x D |
|---|---|---|---|---|---|---|
| Tape | Alum / Poly | Beldfoil® | 100 % | TC - Tinned Copper | 22 | 7x30 |
| Material | Material Trade Name | Nominal Diameter | Nominal Wall Thickness |
|---|---|---|---|
| PVC-LS - Polyvinyl Chloride (Low Smoke) | Flamarrest® | 0.127 x 0.269 in | 0.017 in |
| Nominal Conductor DCR | Nominal Outer Shield DCR |
|---|---|
| 14.1 Ohm/1000ft | 14.3 Ohm/1000ft |
| Nom. Capacitance Conductor to Conductor | Nom. Capacitance Conductor to Other Conductor to Shield |
|---|---|
| 35 pF/ft | 67 pF/ft |
| Nominal Inductance |
|---|
| 0.15 µH/ft |
| Nominal Characteristic Impedance |
|---|
| 42 Ohm |
| Nominal Delay | Nominal Velocity of Propagation (VP) [%] |
|---|---|
| 1.47 ns/ft | 69 % |
| Max. Recommended Current [A] |
|---|
| 2.9 Amps per conductor @ 25°C |
| UL Voltage Rating |
|---|
| 300 V RMS |
| UL Temp Rating: | 60°C |
| Operating Temp Range: | -20°C To +75°C |
| Bulk Cable Weight: | 24 lbs/1000ft |
| Max Recommended Pulling Tension: | 54 lbs |
| Min Bend Radius/Minor Axis: | 2.5 in |
| NEC/(UL) Specification: | CMP |
| CEC/C(UL) Specification: | CMP |
| Environmental Space: | Indoor - Plenum |
| EU Directive 2000/53/EC (ELV): | Yes |
| EU Directive 2003/96/EC (BFR): | Yes |
| EU Directive 2011/65/EU (ROHS II): | Yes |
| EU Directive 2012/19/EU (WEEE): | Yes |
| EU Directive Compliance: | EU Directive 2003/11/EC (BFR) |
| EU CE Mark: | Yes |
| EU RoHS Compliance Date (yyyy-mm-dd): | 2005-04-01 |
| MII Order #39 (China RoHS): | Yes |
| Suitability - Aerial: | No |
| Suitability - Burial: | No |
| Suitability - Hazardous Locations: | No |
| Suitability - Indoor: | Yes |
| Suitability - Outdoor: | No |
| Suitability - Sunlight Resistance: | No |
| UL Flammability: | NFPA 262 |
| CSA Flammability: | FT6 |
| UL voltage rating: | 300 V RMS |
| Plenum (Y/N): | Yes |
| Non-Plenum Number: | 9451D |
| Item # | Color | Putup Type | Length | UPC |
|---|---|---|---|---|
| 9451DP 009Z250 | White | ReelTuff Box | 250 ft | 612825439363 |
| 9451DP 009500 | White | Reel | 500 ft | 612825353249 |
| 9451DP 009Z500 | White | ReelTuff Box | 500 ft | 612825439370 |
| 9451DP 009Z750 | White | ReelTuff Box | 750 ft | 612825252894 |
| 9451DP 0091000 | White | Reel | 1,000 ft | 612825433958 |
| 9451DP 009Z1000 | White | ReelTuff Box | 1,000 ft | 612825439301 |
| 9451DP 0095000 | White | Reel | 5,000 ft | 612825435174 |
| 9451DP 00910000 | White | Reel | 10,000 ft | 612825377030 |
| Footnote: | C - CRATE REEL PUT-UP. |
| Notes: | The jacket and shield are bonded so both can be removed on automatic stripping equipment. Drain wire is inside foil shield. |
| Update and Revision: | Revision Number: 0.268 Revision Date: 05-11-2020 |
