(4)FX UHD Splitter Cassette, OS2, 1x32, 1 Splitter, SC/APC Input, LC/APC Output, Front
| Environmental Space: | Indoor |
| Suitable Applications: | FiberExpress Solutions, Backbone, Telecommunications Room, Main Distribution Room, Data Centers |
| Fiber Type |
|---|
| OS2, G.657.A1, G.652.D |
| Weight: | 0.5 lbs |
| Overall Height: | 1.5 in |
| Overall Width: | 4.5 in |
| Overall Length: | 6.9 in |
| Max Capacity: | 32 Fibers (Output) |
| Wavelength: | 1260-1650 NANOMETERS |
| Front Connection: | Static |
| Termination Style: | Front |
| Operating Temperature Range: | -40°C To +85°C |
| Storage Temperature Range: | -40°C To +85°C |
| Description | Material | Color | Type |
|---|---|---|---|
| Housing | PC/ABS | Black | |
| Cover | Polycarbonate | Black | |
| Frame | PC/ABS | Black | Lead Frame |
| Adapter Output | Plastic - UL94V-0 | Green | LC-Quad w/ Internal Shutters |
| Adapter Input | Plastic - UL94V-0 | Green | SC-Simplex/APC |
| Splitter Configuration | IL Max (dB) | Uniformity Max (dB) | PDL Max (dB) | Directivity Min (dB) | RL Min (dB) |
|---|---|---|---|---|---|
| 1 x 32 | 17.3 | 1.5 | 0.3 | -55 | -55 |
| TIA/EIA Compliance: | Telcordia GR-1209-CORE (splitters only), Telcordia GR-1221-CORE (splitters only) |
| EU Directive 2011/65/EU (RoHS 2): | Yes |
| MII Order #39 (China RoHS): | EUP 50 |
| Related Parts: | FX UHD & FXU Patch Panels, FX Patch Cords |
| Packaging: | Individually packaged in a plastic shell, Shipped in cardboard box (14/box) |
| Update and Revision: | Revision Number: 0.249 Revision Date: 10-07-2025 |
