(4)M12 to 7/8", Power Double-Ended Cordset: Male straight to female straight, 4-pin, Black body, 50 V AC/60 V DC, 8 A; yellow TPE jacket, 1.50 mm² (16 AWG)
| Product Family: | Power Connectors |
| Brand: | Lumberg Automation |
| Connector Type: | Cordset, double ended |
| Shielding: | Unshielded |
| Rated Voltage: | 63 VDC |
| Rated Voltage (UL): | 63 VDC |
| Operating Voltage: | 63 VDC |
| Rated Current*: | 8 A |
| Rated Current (UL)*: | 8 A |
| Product Sub Family: | M12 Power |
| Type of Contact / Gender: | male |
| Connector Design: | straight |
| Attachment Type: | Coupling Nut |
| Number of Pins: | 4 |
| Coding: | L |
| Contact Resistance: | ≤ 10 mOhm |
| Insulation Resistance: | ˃ 10^9 Ohm |
| Mating Cycles: | ≤ 100 |
| Ambient Temperature (Operation)*: | -40 °C to +125 °C, notice derating |
| Protection Degree / IP Rating**: | IP65, IP67 |
| Design Standard: | IEC 61076-2-111 |
| Pollution Degree: | 3 acc. to DIN EN 60664-1 (VDE 0110-1) |
| Clearance / Creepage Distance: | DIN EN 60664-1 (2008/01); VDE 0110-1 |
| Overvoltage Category: | III acc. to DIN EN 60664-1 (VDE 0110-1) |
| Contact Base Material: | CuNi |
| Contact Plating: | Cu/Au |
| Contact Bearer Material: | PBT GF |
| Contact Bearer Color: | black |
| Flammability Class (Contact Bearer): | UL 94 V-2 |
| Molded Body Material: | TPE |
| Molded Body Color: | black |
| Flammability Class (Molded Body): | UL 94 HB |
| Attachment Material: | CuZn |
| Attachment Plating: | Cu/Ni |
| O-Ring Material: | FKM |
| Fastening Torque (Contact Screw): | M 12x1: (60-65) Ncm, hand-tight |
| Cable Number: | 996 |
| Conductor Size: | 1.50 mm² |
| Number of Wires: | 4 |
| Minimal Bending Radius (Fixed Inst): | ˃ 10 x D |
| Minimal Bending Radius (Flexible Inst): | ˃ 10 x D |
| Cycles (Bending): | ˃ 1 Mio |
| Conductor material: | Cu |
| Cable Jacket Material: | TPE |
| Cable Jacket Color: | yellow |
| Cable Diameter D: | Ø 8.7 mm ± 0.2 mm |
| Wire Insulation Material: | PVC / PVC-Polyamid |
| Insulated Wire Diameter: | ø 2.55 mm |
| Overall Shield (Cable): | - |
| Ambient Temperature (Fixed Installation): | -40 °C to +90 °C |
| Ambient Temperature (Flex Installation): | -5 °C to +90 °C |
| Ambient Temperature (Drag Chain Inst): | - |
| UL Cable Type: | UL/CSA, NEC (UL) TC_ER, WTTC or AWM Style 20328 (900 V 105 °C) |
| Flammability Class (Cable Jacket): | UL1685 FT4/IEEE 1202 Vertical Tray Flame Test, FT4 |
| Product Sub Family, Side 2: | 7/8" |
| Type of Contact / Gender, Side 2: | female |
| Connector Design, Side 2: | straight |
| Attachment Type, Side 2: | Coupling nut with internal threads |
| Number of Pins, Side 2: | 4 |
| Ambient Temperature (Operation), Side 2*: | -40°C to +90°C |
| UL-File: | E315587 |
| UL: | UL 2238; cULus |
| RoHS Compliant: | Yes |
| Oil Resistance: | Oil Res II |
| Item # | Item Description | Cable Length |
|---|---|---|
| 934638033 | RST 4L-RK 40-996/1M P-12556 | 1 m |
