(4)PatchPro® - RFID Fiber Panel Upgrade Kit - 48-port - 96 Fiber - enhanced
| Environmental Space: | Indoor |
| Suitable Applications: | Horizontal and building cabling for Intelligent (RFID-based) patching in fiber systems, supporting current and future applications such as 10G Ethernet (10GBase-SR/LR), 40G Ethernet (40GBase-SR4/LR4), 100G Ethernet (100GBase-SR4/LR4), Fibre Channel, FDDI and ATM. |
| Weight: | 449 mm |
| Overall Height: | 15.4 mm |
| Overall Width: | 449 mm |
| Storage Temperature Range: | -20°C To +85°C |
| Description | Material | Color |
|---|---|---|
| LEDs | 48 LEDs - Red | Black |
| Dimensions | (HxWxD) 15.4 x 449 x 4 mm | |
| Antenna Type | 48 port 13.56MHz RFID antenna | |
| Power Consuption | 400 mA max |
| EU Directive 2011/65/EU (RoHS 2): | Yes |
| Related Parts: | It is suitable for use with the following LC Double Cassettes: PPLSMPOM, PPLAMPOM, PPL3MPOM, PPL4MPOM, PPL5MPOM, PPLSMPOM-ALT, PPLAMPOM-ALT, PPL3MPOM-ALT, PPL4MPOM-ALT, and PPL5MPOM-ALT. In addition, it is compatible with the empty panel PP-1U-4DC and the PP range fiber patch cords. |
| Update and Revision: | Revision Number: 0.7 Revision Date: 09-30-2025 |
