(4)Multi-Media, Multi-User Outlet Box, 24 Port
| Suitable Applications: | Compatible with a variety of modules that are suitable for use with Belden IBDN Systems 10GX, 4800,3600, 2400 and 1200. |
| Height: | 2.64 in |
| Width: | 10.68 in |
| Depth: | 10.47 in |
| Port Count: | 24 Port |
| Front Connection: | Flush |
| Packaging: | Individually packaged cardboard box |
| Weight: | 1.5 lbs |
| Description | Material |
|---|---|
| Multi Media Outlet Box | Plastic - UL94V-0 |
| Max Capacity: | 24 inserts, 2 Connector Module Strip |
| Installation Temperature Range: | -10°C To +60°C |
| Storage Temperature Range: | -40°C To +70°C |
| Operating Temperature Range: | -10°C To +60°C |
| Footprint/Type: | MDVO |
| Environmental Space: | Indoor |
| EU Directive 2011/65/EU (RoHS 2): | Yes |
| MII Order #39 (China RoHS): | EUP 50 |
| Suitability - Indoor: | Yes |
| Safety Listing: | Bi-national Standard Listed |
| Related Parts: | Compatible with 10GX, CAT6+ and CAT5E MDVO UTP and Fiber Modules |
| Item # | Color | Port Count |
|---|---|---|
| AX100220 | Almond | 24 Port |
| AX100222 | Black | 24 Port |
| AX100219 | Gray | 24 Port |
| AX100221 | White | 24 Port |
| Included Parts: | Screws, cable tie, instruction sheet, designation labels |
| Notes: | For proper installation refer to the installation guide included with the product or visit our web site at http://www.belden.com |
| Update and Revision: | Revision Number: 0.301 Revision Date: 08-22-2025 |
