(4)FX DCX FRAME, OM3, 04 PORTS, LC DUPLEX, MPO-8 (FEMALE), SR4, AQUA ADAPTERS
| Environmental Space: | Indoor |
| Suitable Applications: | DCX, Data Centers, Central Equipment Room |
| Fiber Type |
|---|
| OM3 |
| Weight: | 0.12 lbs |
| Height: | 0.5 in |
| Width: | 2.25 in |
| Length: | 6.7 in |
| Max Capacity: | 8 Fibers |
| Front Connection: | Static |
| Operating Temperature Range: | -10°C to +60°C |
| Storage Temperature Range: | -10°C to +75°C |
| Description | Material | Color | Type |
|---|---|---|---|
| Adapter Frame Assembly | Polycarbonate | Black | |
| Front Connector Body | Plastic - UL94V-0 | Aqua | LC Duplex |
| Rear Adapter Body | Plastic - UL94V-0 | Aqua | MPO female |
| Adapter Sleeve Material | Zirconia-Ceramic |
| Description | Total Insertion Loss | Total Return Loss |
|---|---|---|
| OM3 | 0.60 dB | -25 dB |
| EU Directive 2011/65/EU (RoHS 2): | Yes |
| MII Order #39 (China RoHS): | EUP 50 |
| Related Parts: | DCX,Frames Modules & Patch Panels |
| Packaging: | Individually packaged in a plastic shell, Shipped in cardboard box |
| Notes: | For more information, please refer to our web site at http://www.belden.com |
| Update and Revision: | Revision Number: 0.7 Revision Date: 05-12-2025 |
