FACEPLATE EUROMOD SERIES - Faceplate Euromod Outlet


EUROMOD (50x25mm) Modular Outlet Faceplate

Product Overview

Environmental Space: Indoor
Suitable Applications: Compatible with a variety of modules that are suitable for use with Belden IBDN Systems 10GX, 4800,3600, 2400 and 1200

Physical Characteristics (Overall)

Height: 86 mm
Width: 86 mm
Depth: 10 mm
Packaging: Individually packaged in a plastic bag.

Connectors

Materials
DescriptionMaterial
FaceplatePlastic - PC-ABS, UL94V-0

Mechanical Characteristics

Footprint/Type: KeyConnect & MDVO
Plug /Jack Compatibility: RJ45

Standards

Telecommunications Standards: ISO/IEC 11801-1:2017

Applicable Environmental and Other Programs

EU Directive 2002/95/EC (RoHS): Yes
EU RoHS Compliance Date (yyyy-mm-dd): 2010-01-01
MII Order #39 (China RoHS): EUP 50

Flammability, LS0H, Toxicity Testing

UL Flammability: UL-94V0

Part Number

Related Parts: Compatible with UTP KeyConnect, UTP MDVO and UTP and Shielded REV Connect Multimedia Modules for 10GX, CAT6+ and CAT5E.
Variants
Item #ColorPort Count
NN01535Black2 Insert
NN01536Black4 Insert
NN01547Grey2 Insert
NN01548Grey4 Insert
NN01523White2 Insert
NN01524White4 Insert

History

Update and Revision: Revision Number: 0.14 Revision Date: 08-08-2019
Date: 2010-01-01
No accessories are available for this product
