BE43007 - Lead Wire, 0.4mm² Solid CN, PVC Ins, 70°C


PVC 0.4mm CuNi

Product Overview

Suitable Applications: Single core non-sheathed cable with solid conductor for internal wiring for conductor temperatures up to 70C

Physical Characteristics (Overall)

Conductor
StrandingMaterialNominal Diameter
SolidBCA - Bare Copper Alloy0.4 mm
Table Notes: Alloy is Copper-Nickel
Conductor Count: 1
Insulation
TypeMaterialNominal DiameterDiameter +/- ToleranceMin. Wall ThicknessNominal Wall Thickness
InsulationPVC - Polyvinyl Chloride0.82 mm0.05 mm0.175 mm0.41 mm

Construction and Dimensions

Min Elongation at Breakof Conductors: 5 %

Electrical Characteristics

Voltage
Voltage Test (In Line)
1 kV AC

Standards

UL AWM Style Compliance: N/A
Military Compliance: N/A

Applicable Environmental and Other Programs

Environmental Space: Indoor
EU RoHS Compliance Date (yyyy-mm-dd): 2000-01-01

Flammability, LS0H, Toxicity Testing

C(UL) Flammability: VW-1
UL voltage rating: N/A

Part Number

Variants
Item #ColorPutup TypeLengthEAN
BE43007.0010KBlackReel10,000 m8719605026293
BE43007.0210KBrownReel10,000 m8719605026316
BE43007.0310KGreenReel10,000 m8719605026323
BE43007.0110KWhiteReel10,000 m8719605026309

History

Update and Revision: Revision Number: 0.130 Revision Date: 07-26-2020
Date: 2000-01-01
