(4)The Tofino Xenon NetConnect Loadable Security Module (LSM) is a plug-in module that provides secure remote discovery, configuration, and validation of Tofino Xenon Industrial Security Appliances over any IP-based network, including corporate WANs and the Internet.
| Name: | TOFINO XENON NetConnect LSM |
| Part Number: | 942140004 |
| Configuration functions: | Secure communication: Uses secure SSH encryption technology to configure each Tofino Xenon Industrial Security Appliance and unique keys generated for every Tofino Xenon Industrial Security Appliance Multiple device configuration: Select one or many Tofino Xenon Industrial Security Appliances to simultaneously apply the device configurations across a plant Verification: Remote verification of firmware versions and configurations, including version tracking and checksum validation Stealth addressing: Uses patented IP address-free communications technology Upgrading firmware: Upload new firmware to Tofino Xenon Industrial Security Appliances over the network |
| Alarm and event actions: | Remotely download event log and diagnostic files over the network |
| Event generation: | All standard Tofino modes supported: • Test: all traffic allowed; alerts generated as per user rules • Operational: traffic filtered and alerts generated as per user rules |
| Modules and components: | • Tofino Xenon Industrial Security Appliance. This new enforcer cannot be run in older systems. They will work for existing Tofino Xenons in the field. • Tofino Firewall/Event Logger LSM • Tofino Configurator version 3.2 |
| Monitoring: | • Automatic auditing of user activity, including configuration changes to either the database or the in-field Tofino Xenon Industrial Security Appliances • All configurations signed to detect tampering or out of sync systems |
| Product Documentation: | https://www.belden.com/products/by-brand/tofino-security |
| Software Download: | https://www.tofinosecurity.com/user/login |
| Update and Revision: | Revision Number: 0.31 Revision Date: 10-14-2025 |
| Item # | Type |
|---|---|
| 942140004 | TOFINO XENON NetConnect LSM |
