(13)19353 - Portable Cordage, (3) 16 AWG (65x34) BC, PVC/PVC, Type SJT
Three 16 AWG stranded (65x34) bare copper conductors, PVC insulation, PVC jacket.
Physical Characteristics (Overall)
| AWG | Stranding | Material | No. of Conductors |
|---|---|---|---|
| 16 | 65x34 | BC - Bare Copper | 3 |
| Conductor Count: | 3 |
| Conductor Size: | 16 AWG |
| Material | Nominal Wall Thickness |
|---|---|
| PVC - Polyvinyl Chloride | 0.033 in |
| Color |
|---|
| Light Blue |
| Brown |
| Green/Yellow |
| Material |
|---|
| Unshielded |
| Material | Nominal Diameter | Nominal Wall Thickness | Separator Material |
|---|---|---|---|
| PVC - Polyvinyl Chloride | 0.353 in | 0.036 in | Paper Tape |
Construction and Dimensions
| Type of Cordage: | SJT |
| Filler |
|---|
| Jute |
| Print Legend: | Surface Impression Printed |
Electrical Characteristics
| Shielding: | Unshielded |
| Max. Recommended Current [A] |
|---|
| 13 Amps per conductor @ 25°C; 10 Amps per conductor @ 25°C (over 50 ft.) |
| 10 Amps per conductor @ 25°C (over 50 ft.) |
| Dielectric Withstand Voltage | UL Voltage Rating |
|---|---|
| 2000 V AC Applied For 1 Min. | 300 V RMS |
| Electrical Characteristics Notes: | Dielectric Withstand Voltage: 2000 V AC Applied For 1 Min |
Temperature Range
| UL Temp Rating: | 60°C |
Mechanical Characteristics
| Bulk Cable Weight: | 72 lbs/1000ft |
Standards
| NEC/(UL) Specification: | SJT |
| CSA AWM Specification: | SJT |
Applicable Environmental and Other Programs
| EU Directive 2000/53/EC (ELV): | Yes |
| EU Directive 2003/96/EC (BFR): | Yes |
| EU Directive 2011/65/EU (ROHS II): | Yes |
| EU Directive 2012/19/EU (WEEE): | Yes |
| EU Directive Compliance: | EU Directive 2003/11/EC (BFR) |
| EU CE Mark: | Yes |
| EU RoHS Compliance Date (yyyy-mm-dd): | 2004-01-01 |
| CA Prop 65 (CJ for Wire & Cable): | Yes |
| MII Order #39 (China RoHS): | Yes |
Flammability, LS0H, Toxicity Testing
| UL voltage rating: | 300 V RMS |
Plenum/Non-Plenum
| Plenum (Y/N): | No |
Part Number
| Item # | Color | Footnote |
|---|---|---|
| 19353 010250 | Black | C |
| Footnote: | C - CRATE REEL PUT-UP. |
