AS-Interface angle connectors; 2 assembled connectors
| Brand: | Belden |
| Product Family: | ASi |
| Product Sub Family: | ASi |
| Item Description: | 0911 ANC 410 |
| Control Cable Interface: | Open End |
| Actuator Supply Voltage (Nominal): | 24 V DC (SELV/PELV) |
| Actuator Supply Voltage (Range): | 10 V DC to 30 V DC |
| Input Wiring: | 2-, 3-, 4-wire |
| CE: | Yes |
| RoHS Compliant: | Yes |
| System Power Supply Connection Note: | *do not connect / disconnect under voltage! |
| Item # | Item Description |
|---|---|
| 15944 | 0911 ANC 410/0,6 M |
| 15946 | 0911 ANC 410/2 M |
| 15945 | 0911 ANC 410/5 M |
| 15932 | 0911 ANC 410/10 M |
| 934637408 | 0911 ANC 410/15 M |
| Update and Revision: | Revision Number: 0.42 Revision Date: 03-04-2023 |
